双排90度短耳扣牛角插座 PH1.27 H11.0
产品分类：间距1.27mm
PH1.27牛角：
PIN 数：2*(3,4,5,7,8,9,10,13,15,1720,25,30,34)P
塑胶高 H：11.0mm
排 数：双排、
折弯类型：90度
材 质：PA6T/PA9T
四 方 针 : 0.4mm
详细介绍
&
Material:
Contact Material: Brass
Contact plating: Au or Sn Over30-50u" Ni
Insulator Material: Black/Gray Polyester UL94V-0
Standard: PA6T/PA9T+30%G.F
Electrical:
Current rating: 1.0Amps/contact max.
Contact resistance: ≤20mΩ/contact
Insulation resistance: ≥500MΩ at V=100V
Withstanding Voltage: 500V AC/minute
Mechanical:
Operaing temperature: -40°C to +105°C
Wave soldering temperature: 260±5°C,10s
