产品中心
双排90度长耳扣牛角 PH2.0 H21.0
产品分类：间距2.0mm
PH2.0牛角：
PIN 数：2*(4,5,6,7,8,9,10,11,12,13,14,15,16,17,18,20,22,25,30,32)P
塑胶高 H：21.0mm
排 数：双排、
折弯类型：90度
材 质：PBT/PA6T/PA9T/LCP
四 方 针 : 0.5mm
详细介绍
&
Material:
Contact Material: Brass
Contact plating: Au or Sn Over30-50u" Ni
Insulator Material: Black/Gray Polyester UL94V-0
Standard: PBT/PA6T/PA9T/LCP+30%G.F
Electrical:
Current rating: 2.0Amps/contact max.
Contact resistance: ≤20mΩ/contact
Insulation resistance: ≥1000MΩ at V=100V
Withstanding Voltage: 500V AC/minute
Mechanical:
Operaing temperature: -40°C to +105°C
Wave soldering temperature: 255±5°C,10s
