单排180度U型排针 PH5.08 H2.5 1x3P
产品分类：间距2.54mm
PIN 数：1*2P~1x40P
塑胶高 H：1.0/1.5/2.0/2.5mm
排 数：单排、
折弯类型：180度/90度/SMT
材 质：PBT/PA6T/PA9T/LCP
四 方 针：0.64mm
详细介绍
&
Material:
Contact Material: Brass
Contact plating: Au or Sn Over30-50u" Ni
Insulator Material: Black Polyester UL94V-0
Standard: PA6T/PA9T/LCP+30%G.F
Electrical:
Current rating: 3.0Amps/contact max.
Contact resistance: ≤20mΩ/contact
Insulation resistance: ≥1000MΩ at V=100V
Withstanding Voltage: 1000V AC/minute
